Orbix Tilting Path Light
Orbix Tilting Path Light
The Orbix Tilting Path Light delivers precision and modern style in a compact form. Featuring a fully integrated 3W CREE LED, this cast aluminum fixture is designed to provide a customizable beam spread with its 60Β° tilting light source. Ideal for illuminating walkways, garden edges, or landscape features, the Orbix offers both performance and flexibility. Finished in textured black for a sleek look, it includes a snap-on hexcell lens and eyelid for advanced glare control and directional lighting.
Orbix Tilting Path Light
| Feature | Specification |
|---|---|
| Housing | Cast Aluminum |
| LED: Watts / VA | Integrated CREE LED 3W (4.5 VA) |
| Adjustability | 60Β° tilting LED for custom light spread |
| Beam Spread / CRI | 60Β° / 85+ |
| Colour Temperature / Lumen | 3000K / 190 Lm |
| Finish | BKT - Textured Black |
| Wiring | 72β of usable #18-2 |
| Operating Range | 9V - 15V AC |
| Dimensions | 8.2β H x 3.15β W |
| Included Accessories | 10β aluminum stake, snap-on hexcell lens, eyelid lens |
| Install Guide | Install every 6 - 10 ft |
| Warranty | 5 Year |
Product Specifications
Dimensions
| Regular | |
|---|---|
| Unit A | 8.2in x 3.15in |
Lighting Specs
| Regular | |
|---|---|
| Watts | 3 |
| Voltage | 12 |
| Lumens | 190 |
| Colour Temp | 3000 |
| CRI | 85 |
| Warranty | 5 year |
| Material | Cast Aluminum |
